PVC Chain Link Fence
- Material: Galvanized wire core with PVC coating
- Wire Gauge: 6GA (4.88mm), 9GA (3.66mm), 11GA (2.95mm), 11.5GA (2.80mm)
- Mesh Size: 3/8″, 1/2″, 5/8″, 3/4″, 1″, 2″
- Height Options: 36″ to 144″ (custom available)
- Roll Length: 50 ft, 100 ft, or customized
- Coating Color: Green, black, brown, white
- Selvage Options: Knuckled or twisted
- Core Wire Standard: ASTM A392 Class 1 and 2
- Packing: Rolls with woven bags or palletized
- HS Code: 73144900
- Estimated Price: $2.90 – $6.80 per meter (depending on gauge and mesh size)
Category：Chain Link Fence, Product
Introduction
PVC chain link fence is a tough, coated mesh system built to handle harsh weather, high security zones, and public areas. It offers strong corrosion protection, an attractive finish, and easy installation.
What is a PVC Chain Link Fence?
A PVC chain link fence is a standard chain link fence coated with polyvinyl chloride for better durability and appearance. Here’s what defines it:
- Core Material: Galvanized steel wire (resists rust)
- Coating: PVC coating adds extra protection and color
- Mesh: Diamond-shaped openings from interwoven wires
- Common Colors: Green, black, brown, white
- Use: Homes, schools, factories, gardens, and sports fields
🕒 Service Life of PVC Chain Link Fence
The typical service life of a PVC chain link fence is:
15 to 25 years, depending on the environment and maintenance.
📌 Key Factors Affecting Lifespan:
- Galvanized Core Wire
Prevents internal rust — lasts long even if PVC cracks. - PVC Coating Quality
Thicker, UV-stabilized coatings last longer (up to 350 microns). - Climate & Location
Coastal or industrial areas may shorten life due to salt or chemicals. - Installation Quality
Proper tensioning, strong posts, and correct fittings ensure durability. - Maintenance
Occasional cleaning and quick repair of damages extend lifespan.
🟢 Typical Lifespan by Environment:
| Environment | Lifespan |
|---|---|
| Normal Urban Areas | 20–25 years |
| Harsh Coastal Zones | 12–18 years |
| Industrial Sites | 15–20 years |
🔷 BMP | Applications
- Residential yards and garden boundaries
- Schools, playgrounds, and sport fields
- Airports, highways, and ports
- Industrial zones and commercial estates
- Prison and military fencing
- Animal enclosures and agricultural areas
🟥 BMP | Benefits of PVC Chain Link Fence
- PVC coating stops rust and corrosion
- Green or black color blends with surroundings
- No welding or knots; fast and easy install
- Withstands high impact and extreme weather
- Complies with ASTM fencing standards
- Offers both knuckled and twisted selvage ends
🟦 BMP | Complete Specifications
📋 General Specifications
| Specification Item | Details |
|---|---|
| Product Name | Chain Link Fence |
| Material | Galvanized low carbon steel wire / stainless steel wire / aluminum alloy |
| Surface Finish | Galvanized + PVC Coated |
| Coating Colors | Green (RAL 6005), Black, Brown, White (Custom Available) |
| PVC Coating Type | Extruded, Extruded & Adhered, Fused & Adhered |
| Standard Compliance | ASTM A392, ASTM 567 |
| HS Code | 73144900 |
📏 Dimensional Specifications PVC Chain Link Fence
| Specification Item | Details |
|---|---|
| Wire Diameter Options | 6 GA (4.88 mm), 9 GA (3.66 mm), 11 GA (2.95 mm), 11.5 GA (2.80 mm) |
| Mesh Aperture Sizes | 3/8″, 1/2″, 5/8″, 3/4″, 1″, 1-3/4″, 2″, 2-1/8″ |
| Mesh Configurations | 30×30 mm, 40×40 mm, 50×50 mm, 60×60 mm, 70×70 mm, 80×80 mm, 100×100 mm |
| Selvage Types | Knuckled / Twisted |
| Fence Height Range | 36″ to 144″ (914 mm to 3657 mm) |
| Roll Length Options | 50 ft (15.24 m), 100 ft (30.48 m), or customized |
🛡️ Performance & Packing Specifications
| Specification Item | Details |
|---|---|
| Breaking Strength | Up to 9650 N (for 6 GA) |
| Zinc Coating Options | 100–610 g/m² (pre or post galvanized) |
| Application Zones | Residential, Commercial, Security, Prison, Airport, Sports Fields, etc. |
| Packaging Method | Woven bags on roll ends, wooden pallet or case (customizable) |
| Estimated Price (FOB) | $2.90 – $6.80 per meter (based on spec and coating type) |
🟪 BMP | Packaging & Delivery PVC Chain Link Fence
- Woven bags at both ends of the roll
- Stretch film and straps for pallet delivery
- Custom packing available on request
- Container loads optimized for 20GP / 40HC
🟫 BMP | Conditions to Consider
- Use smaller mesh (3/8”–1”) for prison or military use
- Choose black PVC for heat-resistance in sun-heavy regions
- Install deeper footings in soft soil areas
- Use twisted selvage for better anti-climb protection
- Combine with razor wire in sensitive zones
🟩 BMP | FAQ PVC Chain Link Fence
Q: Does PVC last longer than galvanized?
Yes. PVC adds a thick plastic layer that resists rust better in coastal or humid climates.
Q: Can it be used with barbed wire?
Yes. BMP supplies fence brackets for adding top barbed or razor wire.
Q: Is the color coating UV-resistant?
Yes. BMP uses UV-stabilized PVC to stop fading for 10+ years.
Q: Can BMP customize mesh and height?
Absolutely. We produce per your mesh size, gauge, and height needs.
Q: What is the standard PVC Chain Link Fence roll size?
Most orders ship in 50 ft rolls, but 100 ft and custom lengths are also available.
🟠 BMP | Feedback from Qatar
“We use BMP’s PVC chain link fence around logistics yards in Doha. It resists dust, sun, and impact. Color still looks new after two years.”
— Project Manager, Logistics Park, Qatar
🟤 BMP | Final Words
PVC chain link fence offers high strength, good looks, and long life. Whether you’re fencing a school, yard, or airport, BMP delivers durable mesh backed by expert service. Select the right mesh size, gauge, and coating for your job. BMP will take care of the rest.
